8825701 Tsunami Compressed Air System Component Filter-Regulator-Lubricator, 1/4″port, 25 SCFM (F/R/L)

$130.15

Description

Tsunami™ Filter-Regulator-Lubricator, 1/4″port, 25 SCFM (F/R/L)
#8825701

These combination Filter/Regulator units are designed for single-station applications. Use one at each air drop to adjust flow for each pneumatic tool for optimal performance and protection. Each head has a port for inclusion of a pressure gage.

These filters offer 20 micron particulate filtration. Quick-Twist release manual drain.

The Tsunami™ Pressure Regulator is an all metal, highly reliable, heavy duty piston regulator. Piston regulators offer higher flow rates than standard diaphragm units. Tsunami™ Pressure regulators also have excellent set pressure stability.

The Tsunami™ Lubricator is powder coated Zamak construction with clear Nylon sight slots and delivers a very high quality proportional flow of lubricant per SCFM of air. Lubricator uses a micrometric regulation effect to dispense oil into the air stream. This method ensures lubrication at a very low flow as well as at very high flow. Adjustment is achieved by turning the slotted needle located inside the flow gage on the head.

Drain Type:Manual

Specifications
Port Size: 1/4″ NPT
Max. Flow: 25 SCFM
Setting Range: 0-160 psi
Tsunami Youtube Playlist

Additional information

Weight 8 lbs
Dimensions 15 x 10 x 5 in
